Related parameters
-
Series
-
Connector Type
Receptacle
-
Mating Part Number
123069-60XX50-HF, 123072-60XX50-HF, 123073-60XX50-HF, 123082-60XX50-HF
-
Material
Copper alloy, high-temperature-resistant resin
-
Pin Count
20–160
-
Pitch
0.5 mm
-
Mated Height
19, 20, 21, 23, 25, 27, 29, 30 mm
-
Floating Range
XY ± 0.8 mm
-
Connection Orientation
Straight (ST)
-
Soldering Process
SMT
-
Rated Current
Signal: 0.5 A/Pin
-
Rated Voltage
50 V AC/DC
-
Withstand Voltage
AC 250 V/min
-
Operating Temperature Range
-40°C to 125°C
-
Transmission Rate
16 Gbps
-
Supported Protocol
-
Power Terminals
5A × 4
-
Mating Cycles
-
RoHS 2
-
Halogen-Free
-
Compatible Replacement
IRISO 10143
-
