WTB3502 Series
The WTB3502 Series is a 3.5 mm pitch, 6-pin wire-to-board PCB connector series using PIP (through-hole reflow) mounting.
Related Parameters
-
Component Type
PCB connector series
-
Pin Count
6
-
Pitch
3.5 mm
-
Material
Terminals: brass; housing: PA6T
-
Rated Current
5 A AC/DC max/pin
-
Withstand Voltage
AC 1800 V/min
-
Contact Resistance
10 mΩ max
-
Operating Temperature Range
−40°C to +105°C
-
PCB Mounting Method
PIP (through-hole reflow)
