Related parameters
-
Series
-
Connector Type
Receptacle
-
Mating Part Number
123023-20XX50-HF
-
Material
Phosphor bronze, LCP
-
Pin Count
60
-
Pitch
0.635 mm
-
Mated Height
—
-
Floating Range
Non-floating
-
Connection Orientation
Right Angle (RA)
-
Soldering Process
SMT
-
Rated Current
0.5 A/Pin
-
Rated Voltage
50 V AC/DC
-
Withstand Voltage
AC 200 V/min
-
Operating Temperature Range
-40°C to 105°C
-
Mating Cycles
100
-
RoHS 2
Compliant
-
Halogen-Free
Yes
-
Compatible Replacement
KEL DW11
-
