Related parameters
-
Series
P2.54-7 Series
-
Material
PA9T
-
Rated Current
6 A max/pin
-
Withstand Voltage
AC 500 V
-
Operating Temperature Range
−40°C to 125°C
-
Contact Resistance
10 mΩ max (initial); 20 mΩ max (after test)
-
Soldering Process
PIP
-
Pin Count
6
-
Pitch
2.54 mm
-
Compatible Replacement
TE C-996340
