123057-20XX50
0.8 mm pitch, 44/124-position right-angle SMT board-to-board plug.
Related parameters
-
Series
BTB0.8-12 Series
-
Connector Type
Plug
-
Pitch
0.8 mm
-
Pin Count
44 or 124 (40 or 120 signal + 4 power)
-
Mating Orientation
Right angle
-
Rated Current
Signal: 0.5 A; power: 5 A max/pin
-
Rated Voltage
100 V AC max
-
Withstand Voltage
300 V AC/min
-
Floating Range
— (not applicable)
-
Operating Temperature Range
−55°C to +105°C
-
PCB Mounting Method
SMT
-
Mating Part Number
123056-20XX50
-
Compatible Replacement
HRS FX18 Series
