101031-20XX50
0.5-10 Series、0.5mm、ZIF、Horizontal（SMT）、Slider、Upper Contact
Related parameters
-
Series
-
Component Type
-
ZIF / Non-ZIF
ZIF
-
Offset Terminal Design
——
-
Rated Current
0.5 A/Pin
-
Rated Voltage
50 V AC/DC
-
Operating Temperature Range
-40°C to 105°C
-
Contact Configuration
Upper Contact
-
FPC/FFC Insertion Direction
Horizontal
-
Connector Width
-
Connector Height
1.26 mm
-
Material
LCP, phosphor bronze
-
Applicable FPC/FFC
Latchless FPC/FFC
-
Mount Type
Horizontal (SMT)
-
Locking Mechanism
Slider
-
Pin Count
4–50
-
Pitch
0.5 mm
-
Compatible Replacement
IRISO 9682 series；Kyocera 6392 series
-
