905201-10XX30
0.8 mm pitch, 120-position SMT board-to-board receptacle with a 5 mm mated height.
Related parameters
-
Series
TB101/TB201 Series
-
Connector Type
Receptacle
-
Pitch
0.8 mm
-
Mated Height
5 mm
-
Pin Count
120
-
Rated Current
0.5 A
-
Rated Voltage
100 V AC/DC
-
Withstand Voltage
AC 500 V/min
-
Operating Temperature Range
−40°C to +105°C
-
PCB Mounting Method
SMT
-
Mating Part Number
905101-10XX30
