WTB2601 Series
The WTB2601 Series is a 2.6 mm pitch, 2-pin wire-to-board PCB connector series using PIP (through-hole reflow) mounting.
Related Parameters
-
Component Type
PCB connector series
-
Pin Count
2
-
Pitch
2.6 mm
-
Material
Terminals / hold-downs: brass; housing: LCP
-
Rated Current
3 A AC/DC max/pin
-
Withstand Voltage
AC 1000 V/min
-
Contact Resistance
16 mΩ max
-
Operating Temperature Range
−40°C to +125°C
-
PCB Mounting Method
PIP (through-hole reflow)
