14119X Series
The 14119X Series is a 1.25 mm pitch, 4-pin wire-to-board PCB connector series using SMT mounting.
Related Parameters
-
Component Type
PCB connector series
-
Pin Count
4
-
Pitch
1.25 mm
-
Material
PA6T
-
Rated Current
1 A AC/DC max/pin
-
Withstand Voltage
AC 500 V/min
-
Contact Resistance
20 mΩ max (initial); 50 mΩ max (after test)
-
Operating Temperature Range
−40°C to +85°C
-
PCB Mounting Method
SMT
