101077-20XX50
1.0-9 Series、1.0mm、ZIF、Horizontal（SMT）、Front flip、Bottom Contact
*101077-20XX50 Product Image
Related parameters
-
Series
-
Component Type
-
ZIF / Non-ZIF
ZIF
-
Offset Terminal Design
——
-
Rated Current
1.0 A/Pin
-
Rated Voltage
50 V AC/DC
-
Operating Temperature Range
-40°C to 105°C
-
Contact Configuration
Bottom Dual Contact
-
FPC/FFC Insertion Direction
Horizontal
-
Connector Width
-
Connector Height
2.50 mm
-
Material
LCP, PA9T, phosphor bronze
-
Applicable FPC/FFC
FPC/FFC with tabs
-
Mount Type
Horizontal (SMT)
-
Locking Mechanism
Front flip
-
Pin Count
4–30
-
Pitch
1.0 mm
-
Compatible Replacement
-
Note
Download
