1.0-7 Series

Related Parameters

• Component Type

• ZIF / Non-ZIF

  ZIF

• Offset Terminal Design

  ——

• Rated Current

  1.0 A/Pin

• Rated Voltage

  50 V AC/DC

• Operating Temperature Range

  -40°C to 105°C

• Contact Configuration

  Bottom Contact

• FPC/FFC Insertion Direction

  Horizontal

• Connector Width

• Connector Height

• Material

• Applicable FPC/FFC

• Mount Type

  Horizontal (SMT)

• Locking Mechanism

  Rear flip

• Pin Count

  4–30

• Pitch

  1.0 mm

• Compatible Replacement

• Note
