0.5-17 Series
0.5 mm pitch, ZIF, vertical insertion, vertical SMT mounting, side-flip lock, front-row-forward/rear-row-forward terminal versions, 4–60 pins, 4.60 mm connector height, for latchless FPC/FFC.
Related Parameters
-
Component Type
-
ZIF / Non-ZIF
ZIF
-
Offset Terminal Design
——
-
Rated Current
0.5 A/Pin
-
Rated Voltage
50 V AC/DC
-
Operating Temperature Range
-40°C to 105°C
-
Contact Configuration
——
-
FPC/FFC Insertion Direction
Vertical
-
Connector Width
-
Connector Height
4.60 mm
-
Material
-
Applicable FPC/FFC
-
Mount Type
Vertical (SMT)
-
Locking Mechanism
Side flip
-
Pin Count
4–60
-
Pitch
0.5 mm
-
Compatible Replacement
-
Note
