0.5-2 Series
The 0.5-2 Series features a slider-lock ZIF design with a 0.5 mm pitch and a 2.00 mm height. Upper-contact and bottom-contact models are available for horizontal insertion, allowing selection to suit the orientation of the exposed conductors. It accepts FPC/FFC without locking tabs.
Related Parameters
-
Component Type
-
ZIF / Non-ZIF
ZIF
-
Offset Terminal Design
——
-
Rated Current
0.5 A/Pin
-
Rated Voltage
50 V AC/DC
-
Operating Temperature Range
-40°C to 105°C
-
Contact Configuration
Bottom Contact / Upper Contact
-
FPC/FFC Insertion Direction
Horizontal
-
Connector Width
-
Connector Height
2.00 mm
-
Material
-
Applicable FPC/FFC
-
Mount Type
Horizontal (SMT)
-
Locking Mechanism
Slider
-
Pin Count
4–50
-
Pitch
0.5 mm
-
Compatible Replacement
IRISO 9685,9686 series；Kyocera 6260, 6212,6262 series
-
