110001-20XX50
1.0-3 Series、1.0mm、NON-ZIF、Vertical（SMT）、Vertical、Front-row
Related parameters
-
Series
-
Component Type
-
ZIF / Non-ZIF
Non-ZIF
-
Offset Terminal Design
Front Row Forward
-
Rated Current
1.0 A/Pin
-
Rated Voltage
50 V AC/DC
-
Operating Temperature Range
-40°C to 105°C
-
Contact Configuration
Dual Contact
-
FPC/FFC Insertion Direction
Vertical
-
Connector Width
-
Connector Height
4.80 mm
-
Material
LCP, phosphor bronze
-
Applicable FPC/FFC
Latchless FPC/FFC
-
Mount Type
Vertical (SMT)
-
Locking Mechanism
No lock
-
Pin Count
3–40
-
Pitch
1.0 mm
-
Compatible Replacement
IRISO 9610,9615 series
-
Note
Natural
