Auto-lock Series
The Auto-lock Series features a 0.5 mm pitch and locks automatically when the FPC/FFC is inserted, eliminating a separate actuator-closing step. It uses bottom contacts and horizontal insertion for FPC/FFC with locking tabs.
Related Parameters
-
Component Type
-
ZIF / Non-ZIF
Non-ZIF
-
Offset Terminal Design
——
-
Rated Current
0.5 A/Pin
-
Rated Voltage
50 V AC/DC
-
Operating Temperature Range
-40°C to 105°C
-
Contact Configuration
Bottom Contact
-
FPC/FFC Insertion Direction
Horizontal
-
Connector Width
-
Connector Height
3.40 mm
-
Material
-
Applicable FPC/FFC
-
Mount Type
Horizontal (SMT)
-
Locking Mechanism
Auto Lock
-
Pin Count
20–60
-
Pitch
0.5 mm
-
Compatible Replacement
IRISO 11501S series
-
Note
If you want to know more about our products
Contact us for product selection and custom connector support.
