24137X Series
The 24137X Series is a 2.00 mm pitch, 2- to 15-pin family of wire-side FFC connector components comprising an FFC housing, FFC terminal, and TPA. Its operating temperature range is −40°C to +125°C.
Related Parameters
-
Pin Count
2 to 15
-
Pitch
2.00 mm
-
Material
Housing: PBT; terminal: copper alloy; TPA: PBT
-
Rated Current
2 A AC/DC max/pin
-
Withstand Voltage
AC 1000 V / DC 1600 V
-
Contact Resistance
10 mΩ max (initial); 20 mΩ max (after test)
-
Operating Temperature Range
−40°C to +125°C
