1.0 Pitch LVDS Cable

Related parameters

• Pitch

  1.0 mm

• Conductor Thickness × Width

  0.035 × 0.65 mm；0.05 × 0.65 mm；0.1 × 0.65 mm

• Pin Count

  30 Pin

• Rated Current

  ≥1 A

• Rated Temperature

  80/105°C

• Conductor Impedance

  <0.96 Ω；<0.63 Ω；<0.35 Ω

• Characteristic Impedance

  100 ± 10 Ω

• Data Transfer Rate

  ≥3.75 GHz

• Note
