Related parameters
-
Series
-
Connector Type
Receptacle
-
Mating Part Number
123030-60XX50-HF
-
Material
Copper alloy, LCP, UL94V-0
-
Pin Count
80
-
Pitch
0.5 mm
-
Mated Height
8 mm
-
Floating Range
—
-
Connection Orientation
Straight (ST)
-
Soldering Process
SMT
-
Rated Current
0.4 A/Pin
-
Rated Voltage
50 V AC/DC
-
Withstand Voltage
AC 200 V/min
-
Operating Temperature Range
-40°C to 105°C
-
Transmission Rate
6 Gbps
-
Supported Protocol
-
Mating Cycles
100
-
RoHS 2
Compliant
-
Halogen-Free
Yes
-
Compatible Replacement
-
Note
Download
