0.5-26B Series
0.5 mm pitch, ZIF, horizontal insertion, horizontal SMT mounting, front-flip lock, bottom contact, 4–70 pins.
Related Parameters
-
Component Type
-
ZIF / Non-ZIF
ZIF
-
Offset Terminal Design
-
Rated Current
0.5 A
-
Rated Voltage
50 V
-
Operating Temperature Range
-40 ℃ ~ 105 ℃
-
Contact Configuration
Bottom Contact
-
FPC/FFC Insertion Direction
Horizontal
-
Connector Width
-
Connector Height
-
Material
-
Applicable FPC/FFC
-
Mount Type
Horizontal (SMT)
-
Locking Mechanism
Front flip
-
Pin Count
4 - 70
-
Pitch
0.5 mm
-
Compatible Replacement
-
Note
