0.4-5 Series
The 0.4-5 Series uses a 0.4 mm pitch front-flip ZIF actuator with two contact points on the bottom side. It accepts tabbed FPC/FFC through horizontal insertion and uses horizontal SMT mounting.
Related Parameters
-
Component Type
-
ZIF / Non-ZIF
ZIF
-
Offset Terminal Design
-
Rated Current
0.4 A
-
Rated Voltage
50 V
-
Operating Temperature Range
-40 ℃ ~ 105 ℃
-
Contact Configuration
Bottom Contact
-
FPC/FFC Insertion Direction
Horizontal
-
Connector Width
-
Connector Height
-
Material
-
Applicable FPC/FFC
-
Mount Type
Horizontal (SMT)
-
Locking Mechanism
Front flip
-
Pin Count
70 ~ 120
-
Pitch
0.4 mm
-
Compatible Replacement
IRISO 12004S series；IRISO 12004 series
-
