123042-60XX50-HF

Related parameters

• Connector Type

  Plug

• Mating Part Number

• Pin Count

  30, 60, 80, 120

• Pitch

  0.5 mm

• Mated Height

  8 mm

• Floating Range

  Non-floating

• Connection Orientation

  Straight (ST)

• Mounting Method

  THR

• Rated Current

• Rated Voltage

• Operating Temperature Range

  -55°C to 105°C

• Transmission Rate

  8 Gbps

• Supported Protocol

  PCI-Express 3.0

• Power Terminal Count

  4

• Mating Cycles

  100

• RoHS 2

  Compliant

• Halogen-Free

  Yes

• Compatible Replacement

  HRS FX23L

• Note
