903004-201220
A 2.2 mm pitch, 12-pin PIP (through-hole reflow) PCB connector assembly in the WTB2202 Series.
Related parameters
-
Series
WTB2202 Series
-
Component Type
PCB connector assembly
-
Pin Count
12
-
Pitch
2.2 mm
-
Material
Terminals: brass; housing: PA10T
-
Rated Current
3 A AC/DC max/pin
-
Withstand Voltage
AC 1000 V / DC 1600 V
-
Contact Resistance
15 mΩ max
-
Operating Temperature Range
−40°C to +105°C
-
PCB Mounting Method
PIP (through-hole reflow)
-
Compatible Replacement
Not specified
