101106-20XX50
Auto Lock Series、0.5mm、Horizontal（SMT）、Auto Lock、Bottom Contact
Related parameters
-
Series
-
Component Type
-
ZIF / Non-ZIF
Non-ZIF
-
Offset Terminal Design
——
-
Rated Current
0.5 A/Pin
-
Rated Voltage
50 V AC/DC
-
Operating Temperature Range
-40°C to 105°C
-
Contact Configuration
Bottom Contact
-
FPC/FFC Insertion Direction
Horizontal
-
Connector Width
-
Connector Height
3.40 mm
-
Material
LCP, UL94V-0
-
Applicable FPC/FFC
FPC/FFC with tabs
-
Mount Type
Horizontal (SMT)
-
Locking Mechanism
Auto Lock
-
Pin Count
20–60
-
Pitch
0.5 mm
-
Compatible Replacement
IRISO 11501S series
-
