160021-3XXX01

Series

SMB 141131X Series

Part Type

Straight waterproof female connector for RG174 cable

Pin Count

1

Material

High-temperature thermoplastic, brass, zinc alloy

Applicable Cable

RG174

Rated Voltage

60 V AC/DC max

Rated Current

1 A AC/DC

Withstand Voltage

500 V AC/min

Insulation Resistance

≥1000 MΩ

Contact Resistance

Center contact / outer conductor: 5 mΩ max (before test); 40 mΩ max (after test)

Operating Temperature Range

−40°C to +105°C

Insertion Force

25 N max

Withdrawal Force

25 N max

Durability

100 cycles

IP Rating

IP68 / IP69

Mating Product

141131-210150

Compatible Replacement

Molex 73404-6470
