0.5-20 Series
The 0.5-20 Series uses a 0.5 mm pitch ZIF slider lock for FPC/FFC with locking tabs. It combines vertical insertion with vertical SMT mounting, with front-row-forward and rear-row-forward terminal versions to suit the required terminal layout.
Related Parameters
-
Component Type
-
ZIF / Non-ZIF
ZIF
-
Offset Terminal Design
Front Row Forward / Rear Row Forward
-
Rated Current
0.5 A/Pin
-
Rated Voltage
50 V AC/DC
-
Operating Temperature Range
-40°C to 105°C
-
Contact Configuration
-
FPC/FFC Insertion Direction
Vertical
-
Connector Width
-
Connector Height
5.47 mm
-
Material
-
Applicable FPC/FFC
-
Mount Type
Vertical (SMT)
-
Locking Mechanism
Slider
-
Pin Count
4–70
-
Pitch
0.5 mm
-
Compatible Replacement
IRISO 9687S series
-
