FPC0519 Series
The FPC0519 Series comprises 0.5 mm pitch, 4–60-position, 1.90 mm high, right-angle SMT FPC/FFC connectors with a front-flip ZIF actuator. It accepts FPC/FFC with locking tabs and operates from −40°C to +125°C.
Related Parameters
-
Pitch
0.5 mm
-
Connector Height
1.90 mm
-
Pin Count
4–60
-
Material
Terminals: copper alloy; insulator: LCP
-
Applicable FPC/FFC
FPC/FFC with locking tabs
-
Locking Method
ZIF front-flip
-
PCB Mounting Method
Right-angle SMT
-
Operating Temperature Range
−40°C to +125°C
