1.0-3 Series

Related Parameters

• Component Type

• ZIF / Non-ZIF

  Non-ZIF

• Offset Terminal Design

  Front Row Forward / Rear Row Forward

• Rated Current

  1.0 A/Pin

• Rated Voltage

  50 V AC/DC

• Operating Temperature Range

  -40°C to 105°C

• Contact Configuration

  Dual Contact

• FPC/FFC Insertion Direction

  Horizontal / Vertical

• Connector Width

• Connector Height

  4.80 mm

• Material

• Applicable FPC/FFC

• Mount Type

  Vertical (SMT)

• Locking Mechanism

  No lock

• Pin Count

  3–40

• Pitch

  1.0 mm

• Compatible Replacement

  IRISO 9610,9615 series

• Note

  Black / Natural
