903005-200820
A 2.5 mm pitch, 8-pin PIP (through-hole reflow) PCB connector assembly in the WTB2501 Series.
Related parameters
-
Series
WTB2501 Series
-
Component Type
PCB connector assembly
-
Pin Count
8
-
Pitch
2.5 mm
-
Material
Terminals: brass; housing: PA10T
-
Rated Current
5 A AC/DC max/pin
-
Withstand Voltage
AC 1000 V / DC 1600 V
-
Contact Resistance
20 mΩ max
-
Operating Temperature Range
−40°C to +105°C
-
PCB Mounting Method
PIP (through-hole reflow)
-
Compatible Replacement
Not specified
