140022-400650
FAKRA Series 90° on-board PCB connector, CODE-F, Brown, for PIP soldering.
Related parameters
-
Series
FAKRA Series 90° On-Board Type
-
Material
HTN, copper alloy, zinc alloy, PA46
-
Housing Color
Brown
-
Characteristic Impedance
50 Ω
-
Frequency Range
DC～6 GHz
-
Contact Resistance
Center contact: 15 mΩ max; outer conductor: 5 mΩ max
-
Rated Current
1 A AC/DC max
-
Withstand Voltage
800 V AC/min
-
Operating Temperature Range
−40°C～+105°C
-
Soldering Process
PIP
-
Compatible Replacement
Rosenberger 59S22B-40MT5-X; Molex 73404-08XX; TE/Tyco 2291392-X; Electric Connector 8180102XX
