140061-20049X

Related parameters

• Series

  HS4.0-2-4P MINI FAKRA Series

• Component Type

  4-pin PCB connector

• Interface Standard

• Pin Count

  4

• Keying / Code

• Connector Orientation

• Connector Configuration

• PCB Mounting Method

  Right-angle

• Soldering Process

• Material

• Rated Voltage

• Rated Current

  1 A AC/DC max

• Withstand Voltage

  500 V DC/min

• Insulation Resistance

• Contact Resistance

  Center contact: 24 mΩ max; outer contact: 10 mΩ max

• Characteristic Impedance

• Operating Temperature Range

  −40°C to +105°C

• Vibration Rating

• Mating Product / Part Number

  160051-33045X

• Compatible Replacement

  TE 2321775
