0.5-18D Series
The 0.5-18D Series uses a 0.5 mm pitch front-flip ZIF actuator that opens and closes by rotating the cover. Bottom contacts and horizontal FPC/FFC insertion are combined with horizontal SMT mounting.
Related Parameters
-
Component Type
-
ZIF / Non-ZIF
ZIF
-
Offset Terminal Design
——
-
Rated Current
0.5 A
-
Rated Voltage
50 V
-
Operating Temperature Range
-40 ℃ ~ 105 ℃
-
Contact Configuration
Bottom Contact
-
FPC/FFC Insertion Direction
Horizontal
-
Connector Width
-
Connector Height
-
Material
-
Applicable FPC/FFC
-
Mount Type
Horizontal (SMT)
-
Locking Mechanism
Front flip
-
Pin Count
4 - 68
-
Pitch
0.5 mm
-
Compatible Replacement
-
Note
