HS0-1-1P FAKRA Series

Related Parameters

• Component Type

• Interface Standard

• Pin Count

  1

• Configuration

  Waterproof female wire harness for RG174 cable; with / without latch

• Keying / Code

• Housing Color

• Connection Orientation

• Applicable Cable

• Soldering Process

• Material

• Rated Voltage

• Rated Current

  1 A AC/DC max

• Withstand Voltage

  500 V AC/min

• Insulation Resistance

• Contact Resistance

  5 mΩ max (initial); 40 mΩ max (after test)

• Characteristic Impedance

• Frequency Range

• Transmission Rate

• Supported Protocol

• Operating Temperature Range

  −40°C to +105°C

• Vibration Rating

• Mating Product / Part Number

• Compatible Replacement

• Note
