1.0-5 Series
The 1.0-5 Series features a 1.0 mm-pitch vertical ZIF design. The FPC/FFC is inserted vertically and secured with a slider lock. Front-row-forward and rear-row-forward terminal configurations are available for FPC/FFC without locking tabs.
Related Parameters
-
Component Type
-
ZIF / Non-ZIF
ZIF
-
Offset Terminal Design
Front Row Forward / Rear Row Forward
-
Rated Current
1 A
-
Rated Voltage
50V AC/DC
-
Operating Temperature Range
-40 ℃ ~ 105 ℃
-
Contact Configuration
-
FPC/FFC Insertion Direction
Vertical
-
Connector Width
-
Connector Height
-
Material
-
Applicable FPC/FFC
Latchless FPC/FFC
-
Mount Type
Vertical (SMT)
-
Locking Mechanism
Slider
-
Pin Count
4 - 40
-
Pitch
1.0
-
Compatible Replacement
Kyocera 9208 series ; MOLEX 52030 series
-
