906001-10XX50
0.4 mm pitch, 9–12-position, 0.90 mm high, right-angle SMT FPC/FFC connector with front insertion and a rear-flip ZIF actuator.
Related parameters
-
Series
-
Component Type
FPC/FFC connector
-
ZIF / Non-ZIF
-
Offset Terminal Design
-
Rated Current
-
Rated Voltage
-
Operating Temperature Range
−40°C to +105°C
-
Contact Configuration
-
FPC/FFC Insertion Direction
-
Connector Width
-
Connector Height
0.90 mm
-
Material
Terminals: phosphor bronze (matte tin-plated); insulator: LCP
-
Applicable FPC/FFC
FPC/FFC with locking tabs
-
Mount Type
Right-angle SMT
-
Locking Mechanism
ZIF, front insertion with rear-flip actuator
-
Pin Count
9–12
-
Pitch
0.4 mm
-
Compatible Replacement
-
