123050-60XX50-HF

Related parameters

• Series

• Connector Type

  Plug

• Mating Part Number

  123045-60XX50-HF

• Material

  Copper alloy, polyamide (nylon), UL94V-0

• Pin Count

  20, 30, 40, 50, 60, 80, 100, 120

• Pitch

  0.5 mm

• Mated Height

  12 mm

• Floating Range

  —

• Connection Orientation

  Straight (ST)

• Soldering Process

  SMT

• Rated Current

  Signal: 0.5 A/Pin

• Rated Voltage

  Signal: 50 V AC; Power: 200 V AC

• Withstand Voltage

  Signal (PIN): AC 150 V/min; Power (PIN): AC 600 V/min

• Operating Temperature Range

  -55°C to 105°C

• Transmission Rate

  8 Gbps

• Supported Protocol

  PCI-Express 3.0

• Power Terminals

  5A × 4

• Mating Cycles

  100

• RoHS 2

  Compliant

• Halogen-Free

  Yes

• Compatible Replacement

  Amphenol B322

• Note
