123072-60XX50-HF

Related parameters

• Connector Type

  Plug

• Mating Part Number

• Pin Count

  20–160

• Pitch

  0.5 mm

• Mated Height

  10, 13, 19 mm

• Floating Range

  XY ± 0.8 mm

• Connection Orientation

  Straight (ST)

• Mounting Method

  SMT

• Rated Current

  Signal: 0.5 A/Pin; Power: 6 A/Pin

• Rated Voltage

  50 V AC/DC

• Operating Temperature Range

  -40°C to 125°C

• Transmission Rate

  16 Gbps

• Supported Protocol

• Power Terminal Count

• Mating Cycles

• RoHS 2

• Halogen-Free

• Compatible Replacement

  IRISO 10143

• Note
