0.5-22B Series
The 0.5-22B Series combines a 0.5 mm pitch front-flip ZIF actuator, a ground pin and compatibility with tabbed FPC/FFC. Bottom contacts, horizontal insertion and horizontal SMT mounting suit layouts requiring both a grounding terminal and cable locking tabs.
Related Parameters
-
Component Type
-
ZIF / Non-ZIF
ZIF
-
Offset Terminal Design
——
-
Rated Current
0.5 A
-
Rated Voltage
50 V
-
Operating Temperature Range
-40°C to 105°C
-
Contact Configuration
Bottom Contact
-
FPC/FFC Insertion Direction
Horizontal
-
Connector Width
-
Connector Height
-
Material
-
Applicable FPC/FFC
-
Mount Type
Horizontal (SMT)
-
Locking Mechanism
Front flip
-
Pin Count
4 - 70
-
Pitch
0.5 mm
-
Compatible Replacement
HRS FH41 series
-
Note
Ground Pin
