123096-60XX50-HF

Related parameters

• Series

  B3501 Series

• Connector Type

  Receptacle

• Mating Part Number

  123095-60XX50-HF

• Material

  Insulator: PA9T; terminals: copper alloy

• Pin Count

  2

• Pitch

  3.5 mm

• Mated Height

  25 mm

• Floating Range

  X/Y/Z: ±1.0 mm

• Connection Orientation

  Vertical

• Soldering Process

  SMT

• Rated Current

  30 A

• Rated Voltage

  400 V AC/DC

• Withstand Voltage

  1000 V AC/min

• Operating Temperature Range

  −40°C to +125°C

• Mating Cycles

• RoHS 2

• Halogen-Free

• Compatible Replacement

  IRISO 10149 Series

• Note
