141251-221260
2.00 mm pitch, 12-position vertical board connector.
Related parameters
-
Series
-
Component Type
Vertical board connector
-
Pin Count
12
-
Pitch
2.00 mm
-
Number of Rows
-
CODE Type
-
With CPA
-
Mating Orientation
-
PCB Mounting Method
SMT
-
Material
LCP
-
Rated Current
4 A AC/DC max/pin
-
Rated Voltage
-
Withstand Voltage
AC 1000 V/min
-
Contact Resistance
20 mΩ max (initial); 50 mΩ max (after test)
-
Operating Temperature Range
−40°C to 125°C
-
Vibration Rating
-
Compatible Replacement
—
