0.5-21 Series
The 0.5-21 Series features a 0.5 mm-pitch vertical ZIF design with a side-flip lock for FPC/FFC with locking tabs. The FPC/FFC is inserted vertically, with front-row-forward and rear-row-forward terminal configurations available to match the PCB pad layout.
Related Parameters
-
Component Type
-
ZIF / Non-ZIF
ZIF
-
Offset Terminal Design
Front Row Forward / Rear Row Forward
-
Rated Current
0.5 A
-
Rated Voltage
50 V
-
Operating Temperature Range
-40°C ~ 105°C
-
Contact Configuration
-
FPC/FFC Insertion Direction
Vertical
-
Connector Width
-
Connector Height
-
Material
-
Applicable FPC/FFC
-
Mount Type
Vertical (SMT)
-
Locking Mechanism
Side flip
-
Pin Count
10 - 70
-
Pitch
0.5 mm
-
Compatible Replacement
HRS FH40 series
-
