1.0-2 Series
The 1.0-2 Series features a 1.0 mm-pitch front-flip ZIF design with dual contacts on the bottom side. The actuator rotates to open and close, and the FPC/FFC is inserted horizontally. It accepts FPC/FFC without locking tabs.
Related Parameters
-
Component Type
-
ZIF / Non-ZIF
ZIF
-
Offset Terminal Design
——
-
Rated Current
1 A
-
Rated Voltage
50V AC/DC
-
Operating Temperature Range
-40 ℃ ~ 105 ℃
-
Contact Configuration
Bottom Contact
-
FPC/FFC Insertion Direction
Horizontal
-
Connector Width
-
Connector Height
-
Material
-
Applicable FPC/FFC
-
Mount Type
Horizontal (SMT)
-
Locking Mechanism
Front flip
-
Pin Count
4 ~ 30
-
Pitch
1.0
-
Compatible Replacement
HRS FH12-XXS-1SH
-
Note
If you want to know more about our products
Contact us for product selection and custom connector support.
