P2.0-7-12P Board Side Series
The P2.0-7-12P Board Connector Series is a 2.00 mm-pitch, 12-position vertical SMT board-side connector series rated at 4 A AC/DC max per pin and −40°C to 125°C.
Related Parameters
-
Component Type
-
Pin Count
12
-
Pitch
2.00 mm
-
Number of Rows
-
CODE Type
-
With CPA
-
Connection Orientation
-
PCB Mounting Method
SMT
-
Soldering Process
-
Material
LCP
-
Rated Current
4 A AC/DC max/pin
-
Rated Voltage
-
Withstand Voltage
AC 1000 V/min
-
Contact Resistance
20 mΩ max (initial); 50 mΩ max (after test)
-
Operating Temperature Range
−40°C to 125°C
-
Vibration Rating
-
Compatible Replacement
-
Note
