101110-20XX50-HF
0.4-5 Series、0.4mm、ZIF、Horizontal（SMT）、Front flip、120Pin
Related parameters
-
Series
-
Component Type
-
ZIF / Non-ZIF
ZIF
-
Offset Terminal Design
——
-
Rated Current
0.4 A/Pin
-
Rated Voltage
50 V AC/DC
-
Operating Temperature Range
-40°C to 105°C
-
Contact Configuration
Bottom Dual Contact
-
FPC/FFC Insertion Direction
Horizontal
-
Connector Width
-
Connector Height
2.5 mm
-
Material
-
Applicable FPC/FFC
FPC/FFC with tabs
-
Mount Type
Horizontal (SMT)
-
Locking Mechanism
Front flip
-
Pin Count
70–120
-
Pitch
0.4 mm
-
Compatible Replacement
IRISO 12004 series
-
Note
