140071-43086X

Related parameters

• Series

  P1.8-5 Series

• Part Type

  P1.8-5A / 5B board-side connector

• Pitch

  1.8 mm

• Pin Count

  8

• Material

  PBT-GF30

• Rated Current

  3 A max/pin

• Withstand Voltage

  AC 500 V

• Operating Temperature Range

  −40°C to +105°C

• Contact Resistance

  10 mΩ max (initial); 40 mΩ max (after test)

• Soldering Process

  DIP

• Compatible Replacement

  IRISO IEMA-13116B-08A-GFM; IEMA-13116B-08B-GFM
