0.5 pitch bending FFC
0.5 mm pitch pre-bent FFC for routed connections in compact spaces.
Related parameters
-
Pitch
0.5 mm
-
Conductor Thickness × Width
0.035 × 0.3 mm；0.05 × 0.3 mm
-
Pin Count
6–96 Pin
-
Rated Current
0.5–2 A
-
Rated Temperature
80/105°C
-
Conductor Impedance
≤1.3 Ω；≤1.41 Ω
-
Characteristic Impedance
120–140 Ω
-
Data Transfer Rate
-
Note
