0.5-1 Series
The 0.5-1 Series features a 0.5 mm-pitch ZIF design with a slider lock that opens and closes by sliding horizontally. Upper-contact and bottom-contact models are available to suit the orientation of the exposed conductors on the FPC/FFC.
*0.5-1 Series Product Image
Related Parameters
-
Component Type
-
ZIF / Non-ZIF
ZIF
-
Offset Terminal Design
——
-
Rated Current
0.5 A
-
Rated Voltage
50 V
-
Operating Temperature Range
-40°C ~ 105°C
-
Contact Configuration
Upper Contact / Bottom Contact
-
FPC/FFC Insertion Direction
Horizontal
-
Connector Width
-
Connector Height
-
Material
-
Applicable FPC/FFC
-
Mount Type
Horizontal (SMT)
-
Locking Mechanism
Slider
-
Pin Count
4 ~ 60
-
Pitch
0.5 mm
-
Compatible Replacement
IRISO 9631, 9632,9633,9634 series ; Kyocera 6222,6223,6239,6268,6269,6210
-
Note
