B0813 Floating Series
Successfully passing the USCAR V3 vibration level test, the connector features a unique dual-independent spring arm design and a micro-stress floating structure, fully meeting the stringent requirements of applications such as three-electric systems and other demanding scenarios.
Related Parameters
-
Connector Type
-
Mating Part Number
-
Material
-
Pin Count
40~120(pin)
-
Pitch
0.8 (mm)
-
Mated Height
18/20/22/24 (mm)
-
Floating Range
X/Y: ±0.8 mm; Z: ±0.5 mm
-
Connection Orientation
-
Soldering Process
SMT
-
Rated Current
0.5A
-
Rated Voltage
125 V AC/DC
-
Withstand Voltage
-
Operating Temperature Range
-40℃ ~ 125℃
-
Transmission Rate
-
Supported Protocol
-
Power Terminals
0
-
Mating Cycles
-
RoHS 2
-
Halogen-Free
-
Compatible Replacement
IRISO 10128 Series
-
Note
Mating Selection & Drawings
|
Fixed side →
Floating side ↓
|
B0813 REC B0813-2110C-HF 2D drawing |
|---|---|
| B0813 PLUG B0813-1110C 2D drawing |
